36' Lapworth L36

Hull Type: Fin Keel Rig Type: Masthead Sloop
LOA: 36.00' / 10.97m LWL: 28.33' / 8.63m
Beam: 9.50' / 2.90m Listed SA: 584 ft2 / 54.25 m2
Draft (max.) 5.50' / 1.68m Draft (min.)
Displacement: 12000 lbs./ 5443 kgs. Ballast:
Sail Area/Disp.1: 17.89 Bal./Disp.: Disp./Len.: 235.61
Designer: C. William Lapworth
Builder: C&J Boatshop (USA)/Taylor Boatworks (CAN)
Construction: Wood (strip planked) Bal. type:
First Built: 1953 Last Built: # Built: 71
AUXILIARY POWER (orig. equip.)
Make: Universal Model: Atomic 4
Type: Gas HP:
RIG AND SAIL PARTICULARS KEY
I(IG): 40.50' / 12.34m J: 13.50' / 4.11m
P: 35.50' / 10.82m E: 17.50' / 5.33m
PY: EY:
ISP: SPL/TPS:
SA(Fore.): 273.38 ft2 / 25.40 m2 SA(Main): 310.63 ft2 / 28.86 m2
Sail Area (100% fore main triangles): 584.00 ft2 / 54.25 m2
Sail Area/Disp.2: 17.89 Est. Forestay Length.: 42.69' / 13.01m
DESIGNER
More about & boats designed by: C. William Lapworth
RELATED LINKS
Lapworth 36 Information www.l-36.com
NOTES
Before his association with Jensen Marine and the CAL boats, this was Bill Lapworth's most successful design, both in numbers and racing success.
