25'4' Ensenada Homebuilt Ken Hankinson Design

25 04 Homebuilt Ensenada Ken Hankinson Design Sailboat.

Pleasure and Racing Sloop started building 1990 and completed 1993.

Original Marine Survey by Robert Lally dated October 20, 1993 $39,500 , 2005 PHRF Sail Rating 180T.

I think this may have changed Rating code 375M.

Taken out of the water in 2010, Re-fit in 2010-2012 Additional costs to boat $20,136.

Minus labor costs as they were completed by Norm Casler Marine survey done by G Dallas Selman, July 6, 2015 by Island Pacific marine Survey Ltd.- replacement cost was determined at $65,000.

Current Market Value at 24,000.

Hull Construction Fiberglass and Epoxy sheathed 38 marine fir plywood over laminated fir frames, stem, keelson, chine logs, hull stiffeners, plywood gussets and knees, plywood throughout with a rake mast, hard chines to a fin keel and a flat transom Stern.

Breadth 710 Depth 56 Board Down, Displacement 3000lbs.

Deck Construction Fiberglass and Epoxy sheathed marine fir plywood over laminated transverse deck beams, sheer clamp, non-opening lexan side windows, fasteners stainless steel and bronze.

Bailast 1,200 lbs retractable lead fin with lower 200lb bulb extension.

Langar Spin Pole tacked to deckmast length 13.83 ft. lock down at racing.

The hull and deck are white colored with copper coat bottom paint. 10 year warranty Deck comprising of a low trunk cabin extending to an open cockpit at the stern Interior with a V-berth in the forepeak, followed by a main cabin with port and starboard settees and quarter berths divided by a centerboard trunk along the center line.

Nexus model NX2 instruments, new DC distribution panel, LED low wattage lighting, new bilge pump and radar reflector.

Stainless steel boarding ladder and safety grips, outboard motor bracket Yamaha 8hp outboard motor with 5 gallon plastic gasoline tank.

Bruce 7kg Anchor with 316 diameter.

Galvanized chain and 716 diameter.

Braided nylon rope 2 X Nexus model start pack, 2 digital depth/speed/triplog and wind combo instruments and handheld anemometer.

Double spreader, deck stepped aluminum mast with 1 X 19 stainless steel wire with cold rolled swage ends to chrome bronze open barrel turnbuckles.

Stainless steel chain plates, sheet stoppers, main sheet and genoa tracks, HARKEN jib furling and cam cleats.

HARKEN no 16st and HARKEN no8 Winches Roller Furling and Snuffer for Genoa North Sails & Storch Sails.

Pleasure Main28.75 Dacron, Pleasure Jib 30.8 Dacron 150 Genoa roller furling Asymmetrical Spinnaker - rip stop nylon, 1 Racing main 26.5 luff X 26.9 leech X 10.2 foot spectra Laminate, 1 Racing jib 30.25luff X 26.75leech X 10.2 foot Spectra laminate, Screecher 32luff X 27.25 X 15 foot 1.5oz nylon light blue and Windseeker 32 luff X 27.8 leech X 9.5 foot 0.75 oz nylon light blue.

Have all original pictures and hours from start to finish and re-fit.

Have All documentation on design, building, components and equipment on boat.

Marine 50ft power cord 2 air dry fans VHF Marine Radio Charts Gulf Islands and Sunshine Coast.
