Equipment: |
Keel Stepped Mast Double Spreader Rig Rod Rigging Navtec marine Hydraulics Backstay Hydraulic Vang Norseman Staylock Turnbuckles Stainless Steel Strap Chain Plates Winches: Ten Barient Winches, Two #37 With Tailing/Hydraulic Mounted In Aft Cockpit, Two #32 With Tailing/Hydraulic Mounted In Cockpit, Two #28 With Tailing/Hydraulic Mounted In Cockpit, Four #27 With Tailing Mast mounted Winches Antal Blocks Antal Mainsheet Traveler Braided and Color Coded Halyards Mainsail Roller Furling Two Randal Hydraulic Staysail and Genoa Roller Furlers. Sails Three North Sails, On Mainsail, One Staysail with UV Protection and one 110 Genoa with UV Protection. Rouhly 1700 square Feet Total sail area.
VHF Furuno Model fm 3000 Icom Command Mic Hm-195B Icom Medel IC-M34 Plotter B&G Model Z12 Furono Nav Net Model RDP-139 B&G Autopilot Depth Sounder B&G Harwich Ship Clock Stereo System Bose Sourround Sound System AM/FM/CD Speakers Bose and Poly-Planar Speakers Around the Vessel. TV Samsung 26"
Batterys 1 Rocket group 24, 730 RC (Genset). Two Bruteforce Group 31 AGM, 1150 CCA, Fourteen Valance, Lithium Group 27 XP Series Model U27-12XP, 138Amp Hr. Main Battery Switches: Seven Rotary Selector Switches, AC/DC Panel Mounted in Nav Station. Breakers/Fuses 36 Individually Switched Breakers at the main Panel. 11 and 8 Breakers on Sub Panels. Leese-Neville Alternator 60 amp Dixie Engine Alternator 90 amp Pro mariner Thruster charger Victron Energy Quattro Model 24V/5000 Watts/120 Amps Eclectic Energy model D400 Wind Generator Monitor. 6 Solar Panels Mounted on Cockpit Enclosure. Victron Monitoring System. Northern Lights Generator 12 KW. M84312N 2282.2 Hr Hubbell 50 Amp 125/250 Volt Inlet
Caterpillar 3208 S/N # 75V09411 210 HP. Twin DIsk Transmission MG506-1 Two Inch Prop Shaft Strong Tides Dripless Packing Gland Two 75900 Max Filter with Water Separators. Generator: Northern Lights Model M84312N S/N 8432448
FG Fresh Water Tank 480 Gallon Capacity Hot Water Tank Atwood modal EHM11-SM 10.5 gallons Heat Exchanger, Hot Water Water Maker: Spectra Watermakers, Model CT-34oz (15.3 Gallons Per Hour) Jabsco Model 83400-0004 4.0 GPM. Dockside Hose Connection FG Sanitation Tanks estimate 50 Gallons Pump Out from Deck or Overboard With Jabsco Macerator 18590-2094 Whale Gulpers and Rule 2000 Pumps for Gray water Overboard Use 2X FG Fuel Tank Total of 560 Gallons LPG Aft deck compartment 2 shut offs.
Stainless Steel Plow Anchors 1 Rocna 55 kg and 1 ABI 60lbs. Chain approximately 300' and 200' of class type BBB Stainless steel Rhode and Swivels. Windlass Two Maxwell Vertical windlass' model 4000 with deck controls.
Life Raft: Winslow 6 person 60540FL ACR Global Fix Pro (Battery Expired) Fireboy 35MA Halon 1301 Automatic Located in the Engine Room Fire Extinguishers x6 Five Type U.S.C.G. Approved PFD's One Throwable PFD Electric Air Horn Search Light First Aid Kit Tapered Wooden Plugs Three Rule 3700 GPH pumps with Remote Float Switches.
MarineAir and Cruise Air, Three Compressors with Three Air Handlers. 2X 1600BTU and 1X 12,000BTU March Model LC-5C-MD 115 Volt Electric Motor. Reverse Cycle for Heat |
